Diesel Power To Do Any Job.

The Hustler® Diesel Z gives you all the great features of a Hustler product paired with fuel-economy of a diesel.

Battery Type
Engine
Deck Sizes
25HP - Perkins
60”RD, 60”, 72”, 72”RD

1

2

3

4

5

6

7

8

9

x graphic
10

x graphic
Close up image of a belt on a mower

Patented Belt Drive System

Provides up to three times longer belt life.

Watch video
Learn More
Image of the back and side of a mower where an air filter has been part way removed

Service Friendly Design

Designed to make maintenance and service simple and easy.

Watch video
Learn More
Close up image of a mower deck on the trimming side of the mower

VX4® Deck

Fabricated steel deck engineered to move more grass at high speeds while maintaining cut-quality.

Watch video
Learn More

Specs

Download specs PDF

Key Specs

Battery Type

Engine Manufacturer

Engine Horsepower

Battery Voltage

Transmission

Fuel Capacity

Ground Speed (FWD)

Cutting Width

Cutting Height

Front Tire

Drive Tire

Warranty

Battery

Engine

Engine Manufacturer

Battery Type

Battery Voltage

Engine Horsepower

Charge Time

Displacement

Watt Hours

Cooling

Air Cleaner

Battery GaUge

Start Method

Engine Warranty

Drive System

Type

Transmission

Hydraulic Lines

Reservoir Capacity

Hydraulic Cooling

Fuel Capacity

Ground Speed (FWD)

Parking Brake

Deck

Cutting Width

Cutting Height

Deck Depth

Deck Lift

Number of Blades

Blade Length

Blade Tip Speed

Spindles

Deck Engagement

Deck Material

Spindle Mounts

IMPACT Trim Area

Anti-Scalp Wheels

Construction

Frame

Engine Plate

Operator Platform

Front AxLE

Front Caster Wheel

Front Caster Fork

General

Seat

Cup Holder

Dimensions

Front Tire (Inches)

Drive Tire (inches)

Wing Tire (inches)

Weight (lbs)

Height (inches)

Length (inches)

Width w/ chute up (inches)

Tire-to-tire Width (inches)

Productivity (acres per hour)

Warranty

Warranty

Dimensions with Catcher

Catcher Style

Powered / Non-Powered

Catcher Capacity

Mower Length w/ Catcher

Mower Width w/ Catcher

Style 2: Catcher Style

Style 2: Powered / Non-Powered

Style 2: Catcher Capacity

Style 2: Mower Length w/ Catcher

Style 2: Mower Width w/ Catcher

Image of the front of a yellow zero-turn mower

Diesel Z

Key Specs

Engine Manufacturer

Perkins

Engine Horsepower

25

Transmission

Tandem Hydro-Gear 21cc pumps with Parker TG wheel motors

Fuel Capacity

14.4 gal.

Ground Speed (FWD)

Up to 11.5 mph

Cutting Width

60", 60" Rear Discharge

Cutting Height

1" to 5.5"

Front Tire

13 x 6.5-6

Drive Tire

24 x 12-12

Warranty

5 Year / 1200 Hour (First 2 Years No Hour Limit)

Engine

Engine Manufacturer

Perkins

Engine Horsepower

25

Displacement

1130cc

Cooling

Liquid cooled, direct-drive, mechanical cooling fan

Air Cleaner

Remote Canister

Engine Warranty

3 Year Limited

Drive System

Type

Dual Hydrostatic

Transmission

Tandem Hydro-Gear 21cc pumps with Parker TG wheel motors

Hydraulic Lines

Stainless steel Parker Seal-Loc Technology

Reservoir Capacity

1.3 gallons

Hydraulic Cooling

Oil Cooler w/ 8" fan

Fuel Capacity

14.4 gal.

Ground Speed (FWD)

Up to 11.5 mph

Parking Brake

Integrated with steering levers

Deck

Cutting Width

60", 60" Rear Discharge

Cutting Height

1" to 5.5"

Deck Depth

5.5"

Deck Lift

Foot Operated

Number of Blades

3

Blade Length

20.50"

Blade Length

18,200

Spindles

Ductile cast iron with steel shaft and sealed ball bearings

Deck Engagement

Electric PTO Clutch

Deck Material

7 gauge welded steel

Spindle Mounts

Reinforced 7 gauge stamped disc

Impanct Trim Area

Front of deck: 11 ga. Formed Bump Bar, Side of deck: 1.5" x .375" steel bar

Anti-Scalp Wheels

Construction

Frame

1.50" X 3" steel tubing

Engine Plate

Operator Platform

Front Axel

Fabricated with sealed ball bearings

Front Caster Wheel

Tapered wheel bearings and debris cap

Front Caster Fork

Fabricated 1/2" steel

General

Seat

I3M Suspension Seat

Cup Holder

Yes

Dimensions

Front Tire (inches)

13 x 6.5-6

Drive Tire (inches)

24 x 12-12

Wing Tire (inches)

Weight (lbs)

1656, 1766 Rear Discharge

Height (inches)

51, 69 w/ ROPS

Length (inches)

86.8

Width w/ chute up (inches)

66

Tire-to-tire Width (inches)

56

Productivity (acres per hour)

5.57

Warranty

Warranty

5 Year / 1200 Hour (First 2 Years No Hour Limit)

Dimensions with Catcher

Catcher Style

Powered / Non-Powered

Catcher Capacity

Mower Length w/ Catcher

Mower Width w/ Catcher

Style 2: Catcher Style

Style 2: Powered / Non-Powered

Style 2: Catcher Capacity

Style 2: Mower Length w/ Catcher

Style 2: Mower Width w/ Catcher

Image of the front of a yellow zero-turn mower

Diesel Z

Key Specs

Engine Manufacturer

Perkins

Engine Horsepower

25

Transmission

Tandem Hydro-Gear 21cc pumps with Parker TG wheel motors

Fuel Capacity

14.4 gal.

Ground Speed (FWD)

Up to 11.5 mph

Cutting Width

72", 72" Rear Discharge

Cutting Height

1" to 5.5"

Front Tire

13 x 6.5-6

Drive Tire

24 x 12-12

Warranty

5 Year / 1200 Hour (First 2 Years No Hour Limit)

Engine

Engine Manufacturer

Perkins

Engine Horsepower

25

Displacement

1130cc

Cooling

Liquid cooled, direct-drive, mechanical cooling fan

Air Cleaner

Remote Canister

Engine Warranty

3 Year Warranty

Drive System

Type

Dual Hydrostatic

Transmission

Tandem Hydro-Gear 21cc pumps with Parker TG wheel motors

Hydraulic Lines

Stainless steel Parker Seal-Loc Technology

Reservoir Capacity

1.3 gallons

Hydraulic Cooling

Oil Cooler w/ 8" fan

Fuel Capacity

14.4 gal.

Ground Speed (FWD)

Up to 11.5 mph

Parking Brake

Integrated with steering levers

Deck

Cutting Width

72", 72" Rear Discharge

Cutting Height

1" to 5.5"

Deck Depth

5.5"

Deck Lift

Foot Operated

Number of Blades

3

Blade Length

24.5"

Blade Length

18,800

Spindles

Ductile cast iron with steel shaft and sealed ball bearings

Deck Engagement

Electric PTO Clutch

Deck Material

7 gauge welded steel

Spindle Mounts

Reinforced 7 gauge stamped disc

Impanct Trim Area

Front of deck: 11 ga. Formed Bump Bar / Side of deck: 1.5" x .375" steel bar

Anti-Scalp Wheels

Construction

Frame

1.5" X 3" steel tubing

Engine Plate

Operator Platform

Front Axel

Fabricated with sealed ball bearings

Front Caster Wheel

Tapered wheel bearings and debris cap

Front Caster Fork

Fabricated 1/2" steel

General

Seat

I3M Suspension Seat

Cup Holder

Yes

Dimensions

Front Tire (inches)

13 x 6.5-6

Drive Tire (inches)

24 x 12-12

Wing Tire (inches)

Weight (lbs)

1711, 1816 Rear Discharge

Height (inches)

51, 69 w/ ROPs

Length (inches)

90.4

Width w/ chute up (inches)

78

Tire-to-tire Width (inches)

56

Productivity (acres per hour)

6.68

Warranty

Warranty

5 Year / 1200 Hour (First 2 Years No Hour Limit)

Dimensions with Catcher

Catcher Style

Powered / Non-Powered

Catcher Capacity

Mower Length w/ Catcher

Mower Width w/ Catcher

Style 2: Catcher Style

Style 2: Powered / Non-Powered

Style 2: Catcher Capacity

Style 2: Mower Length w/ Catcher

Style 2: Mower Width w/ Catcher
